Gauge Pressure Transmitters


Gauge Pressure Transmitter

Gauge Pressure Transmitter

Gauge pressure transmitter with remote diaphragm seal 266GRT

Model 266GRT is the top performance gauge pressure transmitter with remote diaphragm seals suitable for measuring liquid, gas or steam pressure as well as liquid level in open tanks.

Thanks to Taylor’s “All-Welded” technology in remote seal manufacturing as well as to the longstanding expertise, 266GRT can offer unmatched total performances and a wide selection of options such as fill fluid, diaphragm material, capillary protection and mounting connections. ABB, leader in severe process measurements, is able to provide the right solution for the most critical process media at extreme ambient and process conditions. With a long-term stability and its proven reliability, 266GRT represents the best application solution for gauge pressure measurements.


Gauge Pressure Transmitter

Gauge Pressure Transmitter

Gauge pressure transmitter 266GST

Model 266GST is the top performance gauge pressure transmitter suitable for measuring liquid, gas or steam pressure as well as liquid level in an open tank. Thanks to its stability and reliability it works within stated performance even in extreme ambient and process conditions.

In addition to the plug-in terminal block, this transmitter features in-field replaceable electronics module that thanks to the auto-configuration functionality dramatically improves plant productivity. Its intuitive plug-and-play display with easy setup procedure really helps users by saving time and lowering maintenance and inventory costs. Moreover, the innovative TTG (Through The Glass) technology allows users to configure the instruments in the field without removing the windowed front cover and consequently to save a lot of time.


Gauge Pressure Transmitter

Gauge Pressure Transmitter

High overload gauge pressure transmitter with remote diaphragm seal 266HRH

Model 266HRH is a high overload gauge pressure transmitter characterized by the remote seal construction and suitable for measuring liquid, gas or steam flow as well as level, pressure and density.

Thanks to Taylor’s “All-Welded” technology in remote seal design and manufacturing, 266HRH can offer unmatched total performances and a wide selection of options such as fill fluid, diaphragm material, capillary protection and mounting connections. ABB, leader in severe process measurements, is able to provide the right solution for the most critical process media at extreme ambient and process conditions. The long-term stability and its proven reliability make of 266HRH the best application solution for gauge pressure measurements.


Gauge Pressure Transmitter

Gauge Pressure Transmitter

The High Overload Gauge Pressure Transmitter 266HSH

266HSH is a high overload gauge pressure transmitter with a maximum working pressure up to 105 MPa, 15225 psi suitable for measuring liquid, gas or steam pressure in a pipe or on an open tank. Communication options now include Modbus®, along with 4-20mA HART, low-power 1-5V HART, Wireless HART, Profibus, and Foundation Fieldbus.

With a long-term stability, 266HSH grants lasting performances even in extreme ambient and process conditions. In addition to the traditional configuration tool (provided locally via local keys combined with LCD indicator or via hand held terminal or PC configuration tools) the innovative TTG (Through The Glass) technology allows users to configure the instruments in the field without removing the windowed front cover and consequently to save a lot of time, highlighting ABB commitment to satisfy users’ needs of simplicity and flexibility.


Gauge Pressure Transmitter

Gauge Pressure Transmitter

Gauge pressure transmitter P100

Model P100 is the compact, reliable, essential gauge pressure transmitter suitable for liquid, gas or steam applications. It is a straightforward and robust device designed for rapid delivery and easy installation and use. Thanks to its rugged design offering high resistance in even the most demanding environments, it is a competitive solution for most applications, including ones in hazardous areas.

P100 is the new gauge pressure transmitter from ABB, designed to fit markets with standard specifications but subject to fast-to-serve dynamics.

Its compact stainless steel housing grants robustness, resistance to humidity and vibration, while incorporating a new high visibility display with backlight option. Easiness of use of the new touch HMI is enhanced by the Easy Set up feature, a firmware option to easily configure device parameters from the display itself.


Gauge Pressure Transmitter

Gauge Pressure Transmitter

ECONOLINE general purpose pressure transmitter

The Econoline pressure transmitter provides outstanding performance is a wide array of applications, from pipeline pressure to tank level monitoring. It offers several pressure ranges, electrical connections, and analog outputs (current or voltage) to simplify installation and ensure compatibility with most PLC and SCADA systems.

The Econoline is assembled to order in the U.S. and meets the requirements for ARRA Section 1065. Most orders ship in 3 business days or less.

Features:

  • Pressure Ranges - Relative :0 - 30, 50, 100, 150, 200 and 300 PSIG
  • Pressure Ranges - Absolute: 0 - 30, 50, and 100 PSIA
  • Pressure Ranges - Sealed: 0 - 500, 1000, 2000, 3000, 5000, and 10,000 PSIS
  • Accuracy, Static: 0.25% FS Typical, 0.5% FS Max.
  • Accuracy, Total Error Band: 1% FS Max
  • Storage- / Operating Temperature: 0...50 °C / -40...100°C
  • Protection: IP65

Gauge Pressure Transmitter

Gauge Pressure Transmitter

Preciseline High Accuracy Dual Output Pressure Transmitter

The Preciseline high accuracy dual output pressure transmitter provides impressive performance in any new or existing pressure measurement applications. The Preciseline can be calibrated to any pressure range between 2 and 15,000 psi with outstanding Total Error Band (TEB) accuracy, and provides dual outputs; one analog (current or voltage) and one RS485 digital. This versatility ensures compatibility with most SCADA and PLC systems, and makes it possible to connect up to 128 individual Preciseline pressure transmitters on a single bus.

Features:

Pressure Ranges - Relative: Infinite between 0...2 and 0...500 PSIG

Pressure Ranges - Absolute: Infinite between 0...2 and 0...500 PSIA

Pressure Ranges - Sealed: Infinite between 0...500 and 0...15,000 PSIS

Accuracy, Static at 25°C:

  • Standard: 0.1% FS
  • Optional: 0.05% FS

Accuracy, Total Error Band (See Datasheet for Details):

  • Standard: 0.25% BR TEB
  • Optional: 0.1% BR TEB

Compensated Temperature: -10…80°C

Operating Temperature:

  • Cable: -10...60°C
  • Connector: -30...100°C

Protection:

  • IP68 with Cable
  • IP65 with DIN43650 connector

Gauge Pressure Transmitter

Gauge Pressure Transmitter

Preciseline SDI High Accuracy Digital Pressure Transmitter

The Preciseline SDI high accuracy digital pressure transmitter provides impressive performance in any new or existing pressure measurement application using SDI-12 digital communications. The Preciseline SDI can be calibrated to any pressure range between 5 and 450 psi with outstanding Total Error Band (TEB) accuracy, and provides digital outputs; one SDI-12 and one MODBUS-compatible RS485. This versatility ensures compatibility with most SCADA and PLC systems, and makes it possible to connect up to 128 individual Preciseline SDI pressure transmitters on a single bus.

Features:

Pressure Ranges - Relative: Infinite between 0...5 and 0...450 PSIG

Accuracy:

  • Standard: 01% FS TEB
  • Optional: USGS OSW

Compensated Temperature:

  • Standard: -10...80°C
  • Optional: 0...40°C

Operating Temperature:

  • Cable: -10...60°C
  • Connector: -30...100°C

Protection:

  • IP68 with Cable
  • IP65 with MIL-C 26482 connector

Gauge Pressure Transmitter

Gauge Pressure Transmitter

Valueline High Accuracy Pressure Transmitter

The Valueline high accuracy pressure transmitter provides outstanding performance in any new or existing pressure measurement application. The Valueline can be calibrated to any pressure range between 2 and 15,000 psi with outstanding Total Error Band (TEB) accuracy, and provides your choice of analog outputs (current or voltage). This versatility simplifies installation and ensures compatibility with most SCADA and PLC systems.

Features:

Pressure Ranges - Relative: Infinite between 0...2 and 0...500 PSIG

Pressure Ranges - Absolute: Infinite between 0...2 and 0...500 PSIA

Pressure Ranges - Sealed: Infinite between 0...500 and 0...15,000 PSIS

Accuracy, Static at 25°C:

  • Standard: 0.1% FS
  • Optional: 0.05% FS

Accuracy, Total Error Band (See Datasheet for Details):

  • Standard: 0.25% BR TEB
  • Optional: 0.1% BR TEB

Compensated Temperature: -10…80°C

Operating Temperature:

  • Cable: -10…60°C
  • Connector: -30…100°C

Protection:

  • IP68 with Cable
  • IP65 with DIN43650 connector

Gauge Pressure Transmitter

Gauge Pressure Transmitter

Digital Pressure Gauges

Keller digital pressure gauges (a.k.a. digital manometers) are a cost-effective solution in any pressure monitoring scenario where a local display is required. Features include min/max display, selectable units, 5 kHz scan rate for transient capture and data recording. These Swiss-built instruments are commonly used as fuel pressure gauges, water pressure gauges and oil pressure gauges. Almost any installation previously utilizing mechanical or hydraulic pressure gauges can benefit from an upgrade to Keller technology. Manufactured 100% in-house, Keller products incorporate advanced pressure sensor technology combined with the latest in microprocessor-based electronics, resulting in outstanding performance over a wide temperature range at reasonable cost. Whether troubleshooting hydraulics systems or setting up an air-suspension on a military vehicle, Keller digital pressure gauges make the job easier, and they last!


ABB Gauge Pressure Transmitter
